New lincoln K2338-1 175 hd wire feed mig welder kit
Lincoln Electric Weld-Pak 175 HD (Model K2338-1) Wire Feeder MIG Flux Core Welder Kit
This is a brand new Lincoln Electric Weld-Pak 175 HD (Model K2338-1) Wire Feeder MIG Flux-Core Welder Kit. It is complete in its original factory carton and has never been used.
The Weld-Pak 175HD is a complete semiautomatic constant voltage DC portable arc welder. It is an ideal welder for persons having access to 230 or 208 volt 60 Hertz AC input power and is easy to use. It is rated at 130 amps, 20 volts, at 20% duty cycle on a ten minute basis. It is capable of higher output currents at lower duty cycles. A tap-switch controlled, single phase constant voltage transformer/rectifier power source is included along with a wire feeder with welding gun for feeding 0.023†(0.6mm) - 0.035†(0.9mm) solid steel and 0.035†(0.9mm) Innershield® NR-211-MP flux-cored wire. The K549-2 0.045†(1.2 mm) Innershield®. Welding Kit (not included) is required for 0.045†(1.2 mm) Innershield® NR-211-MP flux-cored wire.
The Weld-Pak 175HD offers the dependability of both Gas Metal Arc Welding (GMAW) [also known as Metal Inert Gas (MIG) welding] and the Innershield® electrode process (self shielded flux cored or FCAW). It is perfect for heavy home/farm repair, fabrication, and maintenance projects.
The Weld-Pak 175HD can be used for welding mild steel using the Gas Metal Arc Welding (GMAW) single pass process, which requires a supply of shielding gas (not included), or the flux-cored arc welding (FCAW) process using Innershield® electrode wire.
Weld-Pak 175 HD (Model K2338-1)
* Processes: MIG, Flux-Cored
* Input Voltage/Frequency/Amps: 230/60/20; 208/60/22
* Fuse or Breaker Size: 40 Amp
* Rated CV Output Amps/Volts/Duty Cycle: 130/20/20%
* Maximum Open Circuit Voltage: 33
* Power Cord: 50 Amp, 250V Three Prong Plug (NEMA Type 6-50P)
* Wire Feed Speed Range (IPM): 50 - 400
* Wire Feed Speed Range (M/MIN): 1.3 - 10.2
* Solid Wire Size Range: 0.023†- 0.035†(0.6 - 0.9 mm)
* Cored Wire Size Range: 0.035†(0.9 mm); 0.045†(1.2 mm) with optional K549-2 Kit
* Operates on standard 230V household current.
* Reconnectable for 230 or 208 volt single phase 60 Hz input power.
* Welding procedure chart for mild steel is conveniently located inside the wire feed section door making voltage and wire speed selection a snap!
* Gun trigger safety feature keeps welding wire electrically ‘cold’ until trigger is pressed.
* Overload protection—incorporates both a thermostat and a circuit breaker.
* Quality wire drive with electronic overload protection.
* Quick release idle roll pressure arm is easily adjusted.
* Drive roll is easily reversed to feed 0.030†(0.75 mm) diameter solid wire and 0.035†(0.9 mm) flux-cored diameter wire.
* Complete with everything needed to weld mild steel with self-shielded flux-cored wire right out of the box.
* Factory installed gas solenoid valve for MIG welding.
* MIG welding with gas-shielded solid wire requires shielding gas (gas cylinder and shielding gas not included).
* For welding 0.023-0.035†(0.6 - 0.9 mm) mild steel and stainless steel solid MIG (gas-shielded) wire. Also for 0.035†(0.9 mm) mild steel flux-cored (gasless) wire.
* Welds up to 1/2†steel thickness with 0.045†(1.2 mm) dia NR-212 flux-cored wire (not included).
* 0.045†(1.2 mm) dia NR-212 flux-cored wire requires the K549-2 0.045†(1.2 mm) Innershield® Welding Kit (not included).
* The drive roll incorporated in the K549-2 Kit (not included) must be installed to feed 0.045†(1.2 mm) flux-cored wire.
* The K664-2 Aluminum Feeding Kit (not included) is recommended for welding with 0.035†(0.9 mm) aluminum wire.
* Adjustable wire spool spindle accepts 4†(100 mm) or 8†(200 mm) diameter spools.
* 2) Adjustable Mixed-Gas Regulator
* 4) Magnum® 100L Welding Gun and Cable Assembly¹
* 7) Welding Handshield: #10 filter plate and clear glass cover plate.
* 8) 0.025†(0.6mm) Contact Tips: Three (3)
* 9) 0.035†(0.9mm) Contact Tips: Two (2)
* 10) Hex Key Wrench: For removal of drive roll.
* 11) SuperArc™ L-56 mild steel MIG wire: 2 lb. spool—0.025†(0.6mm)
* 12) Innershield® NR-211-MP flux-cored wire: 1 lb. spool—0.035†(0.9mm)
* 15) Instructional Video: How to Use Wire Feed Welders
* The display stands holding the Operator’s Manual and the Instructional Video are NOT included.
* Original Factory Carton and Packaging
* 20†x 16†x 16†/ 19†x 15†x 15â€
Photographs: All photographs in this listing are of a stock unit and not necessarily the actual item for sale. As such, if there is any cosmetic damage to the original factory carton and/or slight marring of the case as described below it would not be evident in the photographs. It is not our intent to misrepresent our product with a stock photo, but to provide a higher quality series of pictures which highlight the item and showcase the included accessories. All of our photographs are taken in-house and updated as product changes dictate. The photographs are copyrighted and may not be used without permission.
NEW & NEVER USED: We use both NEW and NEVER USED to describe the condition of this welder. By NEW and NEVER USED we mean that the welder is indeed new and not a refurbished unit nor has the welder been used as a demo unit. Please understand though that the carton may have been opened and the packaging may have been disturbed to allow inspection of the contents for completeness.
