47" VERTICAL BORING MILL, O-M VT1-12 Turret &
47" VERTICAL BORING MILL, O-M VT1-12 Turret &
63” OM DOUBLE COLUMN VERTICAL BORING MILL,
TABLE DIAMETER ......................... 47.24”
MAX. TURNING DIA(SIDE HEAD DOWN) ....... 63”
MAX. TURNING DIA(SIDE HEAD IN POSITION). 55.12
MAX. TURNING HEIGHT .................... 37.4”
MAX. WEIGHT OF WORK PIECE .............. 11,000 LBS
VERTICAL TRAVEL OF TURRET HEAD SLIDE ... 35.43”
HORIZONTAL TRAVEL OF TURRET HEAD ....... 39.37”
SWIVEL OF TURRET HEAD .................. °±30
VERTICAL TRAVEL OF SIDE HEAD ........... 34.25”
HORIZONTAL TRAVEL OF SIDE HEAD RAM ..... 23.62”
SIZE OF TOOL ........................... 1.38” X 1.38”
MAX. HEIGHT UNDER CROSS RAIL ........... 43.3”
VERTICAL TRAVEL OF CROSS RAIL .......... 27.56”
12 TABLE SPEEDS ........................ 5.1-280 RPM
12 FEEDS ............................... .0028-.118 IPR
RAPID TRAVERSE RATE .................... 104 IPM
APPROX. WEIGHT ......................... 27,500 LBS
DIMENSIONS ............................. 117”X 114”X 165.9”
- T-SLOTTED TABLE WITH SET OF (4) FACE PLATE JAWS
- R.H. SIDE HEAD WITH SQUARE TOOL HOLDER
- 27 HP MAIN DRIVE MOTOR W/ CONTROLS
Machine Location: WILMINGTON, DE
