1991 CINCINNATI MONOSET TOOL & CUTTER GRINDER, TOOLED
1991 CINCINNATI MONOSET TOOL & CUTTER GRINDER, TOOLED
CINCINNATI-MILACRON "MONOSET" TOOL & CUTTER GRINDER
MODEL: MT S/N: 4898A0191-0032 NEW: 1991
WORKHEAD SWING OVER MAIN SLIDE, MAX. DIA. ... 12"
MAX. WORKHEAD COLLET HOLE DIA. .............. 1-1/4"
MIN. WORKHEAD COLLET HOLE DIA. .............. 0.12"
MAX. GRINDING WHEEL DIA. .................... 4"
MAX. LENGTH OF WORK BETWEEN SPINDLE &
TAILSTOCK CENTER .......................... 6"
LONGITUDINAL .............................. 5-3/4"
CROSS ..................................... 5-3/4"
MAX. TURNTABLE SWIVEL ..................... 235 DEG.
ABOVE AND BELOW CENTER .................... 40 DEG.
LONGITUDINAL .............................. 6"
CROSS ..................................... 7-1/2"
ABOVE CENTER .............................. 4.5"
BELOW CENTER .............................. 5"
(3) WHEELHEAD SPINDLE SPEEDS ................ 4,000,
(1) WORKHEAD SPINDLE SPEED ................. 436 RPM
APPROXIMATE WEIGHT ........................ 1,500 LBS.
1/4 HP 3/60/230-460 VOLT MOTORIZED WORKHEAD
BIJUR ONE-SHOT LUBRICATION SYSTEM
1/2 HP 230-460 VOLT WHEELHEAD DRIVE MOTOR
MACHINE IS PRESENTLY WIRED FOR 3/60/460 VOLTS
(6) TAPER HOLE COLLETS "C" SERIES
.... #5 B & S, #7 B &S & #9 B & S
(13) STRAIGHT CYCLINDRICAL COLLETS
.... SERIES "A", 1/8", 3/16", 1/4", 5/16", 3/8", 7/16"
.... SERIES "C", 5/8" 3/4", 7/8", 1", 1- 1/8" & 1- 1/4"
INTERNAL GRINDING ATTACHMENT COMPLETE WITH I.D. SPINDLE.
UNIT MOUNTS ON THE WHEELHEAD. I.D. SPINDLE SPEEDS ARE
GRINDING WHEELHEAD TOOTHREST & EXTENSION BAR FOR TAILSTOCK
ADJUSTABLE TAIL-CENTER SUPPORT
(2) INDEX PLATES, "10" DIVISIONS & "12" DIVISIONS
** EXCEPTIONAL CONDITION & APPEARANCE (ORIGINAL PAINT) **
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
Machine Location: HARRISON, NJ
