9-axis Optical Positioning Device Nicolet XRD X-ray diffraction mechanical guts.
Best we can tell, this is the mechanical guts of an early Nicolet X-ray Diffraction system. A current generation unit can be seen at the following link.
http:// /com/cda/product/detail/1,,11201,00.html
Basically what this unit has left is a number of precision rotational and linear movements. There were two primary motorized drives that turned worm gears at the base. One dive mechanism is still in place except for the motor. The other is missing back to the main gear. There are a pair of ring gears in the open circle at the top of the unit.
The cover half on the left above has a leveling bubble. The right half cover is missing.
There is a Bausch & Lomb eye-piece viewer for determining the exact analysis spot (if it were a complete unit)
There are a total of some 9 graduated scales by my count. We have attempted to image most of them here.
The hole in the lower left above is where the motor drive for the upper base ring gear should go. It was for driving the long swinging arm. In the two images below you see the lower worm gear drive that is in place which drives the mechanism attached to the upper rotary scale.
The image above shows the motor mount for the lower worm gear drive.
The image below shows the two ring gears in the donut on the top of the machine. We assume motor drives for them originally mounted here.
Additional similar items may be available or listed separately.
Might be just what you need for your elaborate precision optical positioning application.
Condition looks used cannibalized as shown above.
