Tek 527 svc/op manual in 2 res and A3 + A4 +text search
Tektronix 527 Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
For page samples from this specific manual, click HERE.
We appreciate your considering purchase of these very high-resolution and standard resolution scanned copies of the SERVICE AND OPERATING MANUAL for the Model 527 Waveform Monitor. These volumes are each composed of the entire contents of the original manual. We supply PDFs in both a very high res and a faster, less resource-demanding "standard" resolution. The standard res A4 Manual PDF is also TEXT-SEARCHABLE.
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus full operating information.
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 400-600dpi grayscale (contrast adjusted, content-dependent)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color: 400-600dpi 24 Million colors
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
Also, we include a "foldouts.pdf" with the foldout pages from the manual scanned 17x11". Please note that the foldout pages are ALSO included as ~A4 scans (sectioned as 8.5 x 11" pages, in other words) in the main manual for ease of printing on standard printers.
