Hp 8753A & 85047A ops, prog. & service manuals (3 vol)
VOLUME 1: 8753A NETWORK ANALYZER, SYSTEM OPERATING AND PROGRAMMING
* Electronic page numbers = Original Page numbers (8-D-1, 8-D-2, etc)
* 442 Pages in a 15 MB PDF format file on CD-ROM
* Serial Numbers covered 2543A, 2606A, 2618, 2620A, and 2625A
VOLUME 2: 8753A NETWORK ANALYZER, ON-SITE SYSTEM SERVICE MANUAL
* (DETAILED) Troubleshooting
* 300dpi TEXT, Full Size A3 11x17 scans of Foldouts
* Electronic page numbers = Original Page numbers (8-D-1, 8-D-2, etc)
* 316 Pages in a 12 MB PDF format file on CD-ROM
* Serial Numbers covered 2543A, 2606A, 2618, and 2620A
* NOTE: There are NO DETAILED BOARD LEVEL SCHMATICS (Sorry)
VOLUME 3: 85047A S-PARAMETER TEST SET OPERATING AND SERVICE MANUAL
* Electronic page numbers = Original Page numbers (8-D-1, 8-D-2, etc)
* 56 Pages in a 6 MB PDF format file on CD-ROM
* Serial Numbers covered 2819A
Also included is a copy of Application Note 326 on "Principles of Microwave Connector Care", 84 Pages in 5MB.
THIS CD WAS REPRODUCED WITH PERMISSION: COURTESY OF AGILENT TECHNOLOGIES INC.
Samples from the actual scan available on request jsut drop us an email
