Cmos 4012 - dual 4-input nand gate - nos
CD4011B, CD4012B, and CD4023B NAND gates provide the system designer with direct implementation of the NAND function and supplement the existing family of CMOS gates. All inputs and outputs are buffered.
* Propagation delay time = 60 ns (typ.) at CL = 50 pF, VDD = 10 V
* Buffered inputs and outputs
* Standardized symmetrical output characteristics
* Maximum input current of 1 µA at 18 V over-full package temperature range; 100 nA at 18 V and 25°C
* 100% tested for quiescent current at 20 V
* 5-V, 10-V, and 15-V parametric ratings
* Noise margin (over full package temperature range:
* Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of "B" Series CMOS Devices"
Datasheet link: http://www-s.ti.com/sc/ds/cd4012b.pdf
