Tek 475 DM44 opt-07 service & operations -8 manual set
1) Tektronix 475 200MHz OSCILLOSCOPE; SERVICE MANUAL: Tektronix P/N 070-1332-00. This is a reproduction grade scan of the original commercial manual, comprising 226-pages in a 493-MB pdf file. This manual includes basic operating instructions, specifications, theory of operation, performance checks, adjustment and calibration , maintenance and troubleshooting , Options, Electrical and Mechanical parts, Schematics and board overlay parts locators. All foldout pages were done as FULL SIZE A3 11x17 Scans. Serial numbers directly referenced include B010100 through "B070000 & Above"
2) Tektronix DM44 DIGITAL MULTIMETER with OPTIONS; SERVICE MANUAL. This is a reproduction grade scan of the original later printing commercial Tektronix manual, part# 070-2036-01 It covers operations, service, theory of operation, calibration and adjustment, parts lists, board layouts and schematic diagrams. Serial numbers directly referenced B010100 up through B269250. 167-pages in 28-MB in PDF format. Extensive bookmarks and the electronic page numbers = orignal page numbers (1-1, 2-14 , etc) FULL SIZE A3 11x 17 scans of schematics and fold outs
3) 475 Option-07, 12-VDC Operation, High resolution scan of the original Tektronix manual part # 070-1747-00, 33-pages, 4MB PDF file. Full SIze schematics, Bookmarked, Electronic page numbers = Original Page numbers, Hyperlinked Table of Contents.
In addition to the scans above we have also included (5) five US Government declassified service, calibration and maintenance manuals for the OS-261B and OS-261C (US government nomenclature numbers for the Tektronix 475 scope).
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
FULL SIZE A3 (11X17) SCANS OF THE FOLDOUTS
(IF THE OTHER GUYS ARE ONLY CHARGING $.01 MAYBE THAT'S WHAT THEIR CD's ARE WORTH?
SORT OF LIKE OATS THAT HAVE ALREADY BEEN THROUGH THE HORSE..
SATISFACTION GUARANTEED OR YOUR MONEY BACK !
