30" OPTICAL COMPARATOR, Jones & Lamson Epic-2
30" OPTICAL COMPARATOR, Jones & Lamson Epic-2
30" JONES & LAMSON (MADE IN USA)
OPTICAL COMPARATOR & MEASURING MACHINE
MODEL: EPIC-230 S/N: E-72161 NEW: 1980
SCREEN DIAMETER ................................ 30"
SIZE OF WORK TABLE ........................ 8-1/2" X 32"
MEASURING CAPACITY (TRAVEL OF WORK TABLE)
LONGITUDINAL ................................... 12"
VERTICAL ........................................ 9"
ANGULAR MEASURING CAPACITY...... 360 DEG. CHART ROTATION
HELIX ANGLE ADJUSTMENT (TABLE SWIVELS, L&R)...... 15 DEG
CROSS TRAVEL FOR FOCUSING ....................... 3"
MAXIMUM THROAT CLEARANCE ........................ 30"
DISTANCE FOCAL PLANE TO ERECTOR LENS ............ 13"
DISTANCE FOCAL PLANE TO CONDENSING LENS ......... 17"
DISTANCE, LENS CENTERLINE TO TABLE:
MAXIMUM ......................................... 10"
MINIMUM ......................................... 1"
FLOOR SPACE ...................... 61"LR X 123"FB X 82"H
MACHINE WEIGHT ............................... 5,200 LBS
6-POSITION POWER LENS TURRET (SEVERAL LENSES)
** EXCELLENT CONDITION & APPEARANCE **
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
Machine Location: HARRISON, NJ
